7-Way Solderless Wiring Harness – With Volume Clarity Select

Expand your Strat’s tonal range with the Calitone 7-Way Solderless Wiring Harness, designed for players who want both classic single-coil sparkle and versatile new combinations. Built with premium CTS pots, a Fender 5-way switch, and our exclusive Volume Clarity Select, this harness keeps your highs crisp at every volume while unlocking sounds you can’t get from stock wiring.

Features

  • 1 × CTS 250k Audio Taper Volume Pot – Smooth, responsive control.

  • 1 × CTS 250k DPDT Push-Pull Tone Pot – Unlocks expanded pickup combinations.

  • 1 × CTS 250k Tone Pot – Classic Strat-style tone roll-off.

  • Capacitor: 0.047µF – Vintage warmth with articulate highs.

  • Fender 5-Way Selector Switch – Reliable Strat pickup switching.

  • Solderless PCB System – Quick-connect installation, no soldering required.

  • Vintage Cloth Push-Back Wire – Authentic style and durability.

Volume Clarity Select (Treble Bleed Circuit):

  • 1000pF / 150k Parallel – Balanced, natural clarity. Volume taper is smoother, like a linear pot.

  • 1000pF / 150k Series – Brighter, cutting response. Volume taper behaves more like an audio pot.

Pickup Combinations (7-Way Switching)

With the push-pull tone pot down (standard 5-way):

  1. Bridge

  2. Bridge + Middle

  3. Middle

  4. Middle + Neck

  5. Neck

With the push-pull tone pot up (expanded 7-way):

  1. Bridge + Neck (Tele-style chime)

  2. Bridge + Middle + Neck (all three pickups)

  3. Middle

  4. Middle + Neck + Bridge

  5. Neck + Bridge

Why Choose This Harness?

This harness expands your Strat with two extra pickup positions plus Volume Clarity Select, giving you everything from glassy Strat tones to Tele-style blends and full 3-pickup sparkle — all while keeping your tone crisp at every volume setting.

A professional-grade, solderless upgrade that combines vintage feel, modern clarity, and maximum versatility.

Disclaimer: Some Stratocaster pickguards may require slight widening of the pot holes to fit full-size CTS pots (1/4" 6.5mm). We recommend using a guitar tuner reamer for a clean and safe adjustment. This harness uses 24 fine spline knobs. Smaller metric knobs will not fit. Fits Fender Stratocaster & Squire Stratocasters with modification.
